| ชื่อแบรนด์: | SZSSTH/OEM |
| เลขรุ่น: | RA |
| ขั้นต่ำ: | 5 pieces |
| ราคา: | CN¥1,315.79/pieces |
Professional-grade power conversion solution for solar and off-grid applications, featuring true pure sine wave output for sensitive electronics.
| Network | SDK |
| Type | DC/AC Inverters |
| Output Type | DUAL |
| Output Current | Load |
| Output Frequency | 50Hz/60Hz |
| Size | 241*345*121 mm |
| Weight | 6.1KG |
| Output waveform | Pure Sine Wave |
| Rated power | 3000W |
| Peak power | 6000W |
| Shell Material | Iron |
| Applicable Battery Type | Lead acid/LiFePO4/NCM battery |
| Charging Method | Constant current/constant voltage (CC/Cv) |
| Cooling Method | Air Cooling |
| Operating Temperature | -10℃~+45℃ |
| Warranty | 12 Months |
| Input | Output | ||
|---|---|---|---|
| Voltage Range | 180~264VAC | Rated Voltage | 220Vac @≥12.5 VDC |
| Frequency Range | 47-63HZ | Rated Current | 13.64A @≥12.5VDC |
| Maximum Efficiency | ≥91% @220VAC | Output Frequency | 50Hz/60Hz |
| Maximum Current | 15Amax | Maximum Power | 3000W (peak power 6000W) @≥12VDC |
| PF value | ≥0.95 | Power Factor | ≥0.95 |
| Surge Current | ＜60A Cold Start | THD | ≤3% (resistive load) |
| Applicable Battery Type | Lead acid/LiFePO4/NCM battery |
| Charging Voltage | 10.5V-14.5V |
| Charging Method | Constant current/constant voltage (CC/CV) |
